1.25G SFP BIDI TX1490/RX1550NM 80KM DDM
1.25G SFP BIDI TX1490/RX1550NM 80KM DDM
Item : TSB-1245X-80-X
Inquiry
Name Value Descriptions SFP BIDI TX1470 Date Rate 1.25G TX DFP RX PIN Reach 80KM Output Power(dBm) -2~3 Sensitivity (dBm) -25 Temperature (℃) 0-70
The SFP-BIDI transceivers are high performance, cost effective modules supporting dual data-rate of 1.25Gbps/1.0625Gbps and 80km transmission distance with SMF.
Dual data-rate of 1.25Gbps/1.063Gbps operation
1490nm DFB laser and PIN photodetector for 80km transmission
Compliant with SFP MSA and SFF-8472 with simplex LC receptacle
Digital Diagnostic Monitoring:
Internal Calibration or External Calibration
Compatible with RoHS
+3.3V single power supply
Operating case temperature:
Standard : 0 to +70°C
