Technical item |
Details |
|
PON Interface |
1 XPON BoB（Class B+） |
|
Receiving sensitivity:≤-27dBm |
|
|
Transmitting optical power: +0.5~+5dBm |
|
|
Transmission distance: 20KM |
|
|
Wavelength |
TX: 1310nm, RX: 1490nm |
|
Optical Interface |
SC/UPC Connector |
|
Design Scheme |
ECONET7526 |
|
Chip Spec |
CPU 950MHz,DDR2 256MB |
|
Flash |
SPI NAND Flash 128MB |
|
LAN Interface |
4 x 10/100/1000Mbps auto adaptive Ethernet interfaces. Full/Half, RJ45 connector |
|
Wireless |
Compliant with IEEE802.11b/g/n,ac |
|
2.4G Operating frequency:2.400-2.4835GHz |
|
|
5.8G Operating frequency:5.150-5.825GHz |
|
|
2.4G 2*2 MIMO, rate up to 300Mbps |
|
|
5.8G 2*2 MIMO ,rate up to 867Mbps |
|
|
2 external antennas 5dBi |
|
|
Support Multiple SSID |
|
|
POTSinterface |
1 FXS, RJ11connector Support: G.711/G.723/G.726/G.729codec Support: T.30/T.38/G.711 Fax mode, DTMFRelay Line testing according toGR-909 |
|
LED |
9 LED, For Status of PWR、LOS、PON、LAN1~LAN4、2.4G、5.8G |
|
Push-Button |
2 ,For Function of Reset and WPS |
|
Operating Condition |
Temperature: 0℃~+50℃ |
|
Humidity: 10%～90%（non-condensing） |
|
|
Storing Condition |
Temperature: -30℃~+60℃ |
|
Humidity: 10%~90%（non-condensing） |
|
|
Power Supply |
DC 12V/1A |
|
Power Consumption |
≤6W |
|
Dimension |
248mm×158mm×192mm（L×W×H） |
|
Net Weight |
0.3Kg |
|
Storing Condition |
Temperature: -30℃~+60℃ |
