| Item | Parameters | Specification |
| Interface | PON Port | 1 EPON optical interface Meet 1000base-PX20+ standard Symmetric 1.25Gbps upstream/downstream SC single-mode fiber split ratio: 1:64 Transmission distance 20KM Receiving sensitivity:≤-28dBm Transmitting optical power:0~+4dBm |
| Ethernet Port(LAN) | 4*GE Auto-negotiation RJ45 ports Full Duplex / Half-Duplex RJ45 Auto-MDI/MDI-X Transmission Distance 100 Meter |
|
| Management | NetworkManagement | Support IEEE802.3 QAM ONU can be remotely managed by OLT Support Remote management through SNMP and Telnet Local management |
| Management Function |
Status monitor Configuration management Alarm management Log management |
