| Connector A | SC UPC | Connector B | SC UPC |
| Fiber Type | OM3 50/125μm Multimode | Wavelength | 850/1300nm |
| Fiber Count | Duplex | Distance | Customized |
| Glass Fiber | Corning ClearCurve® | Cable Jacket | PVC/LSZH/OFNP |
| Insertion Loss | ≤0.3dB | Return Loss | ≥20dB |
| Attenuation at 850nm | 3.0dB/km | Attenuation at 1300nm | 1.0dB/km |
| Cable Diameter | 2.0mm | Fiber Color | Aqua |
| Application | 10G/40G Networks | Minimum Bend Radius | 7.5mm |
| Operating Temperature | -20°C to +70°C | Storage Temperature | -40°C to +85°C |
